Pulling Injection Pumps
In-house build-up, assembly, testing, and calibration. Built-up with top quality parts, machine work, and customization for maximum performance.
Ambac Model 100
-
-10mm Plunger Head, (stock lift cam, up to 220cc)
-
-13mm Plunger Head (high lift 6mm lift cam, up to 625cc)
-
-3,000 / 3,500 / 4,500 RPM governor options
CAV DPA Rotary
-
-10mm Plunger CAV Head (up to 300cc)
-
-.450" Plunger Stanadyne Head (up to 400cc)
-
-3,000 / 3,500 / 4,500 RPM governor options
Stanadyne DB Rotary
-
-.370″ Plunger Head (up to 300cc)
-
-.450″ Plunger Head (up to 400cc)
-
-3,000 / 3,500 / 4,500 RPM governor options
Bosch A-Pump
-
-10mm Plungers (stock 8mm lift cam, up to 450cc)
-
-10mm Plungers (X386 or X388 9mm lift cam, up to 500cc)
-
-10mm Plungers (X387 10mm lift cam, up to 550cc)
-
-13mm Plungers (X386 9mm lift cam, up to 900cc)
-
-3,000 / 3,500 / 4,500 & open RPM governor options
Bosch P-3000
-
-13mm Plungers (X390 or X393 12mm lift cam, up to 850cc)
-
-13mm Plungers (X398 12mm lift cam, up to 900cc)
-
-13mm Plungers (X393 12mm lift cam, up to 1100cc)
-
-14mm Plungers (X480 12.5mm lift cam, up to 1200cc)
-
-3,000 / 3,500 / 4,500 & open RPM governor options
Bosch P-7100
-
-13mm Plungers (X501 12mm lift cam, up to 950cc)
-
-13mm Plungers (X540 14mm lift cam, up to 1050cc)
-
-14mm Plungers (X501 12mm lift cam, up to 1250c)
-
-14mm Plungers (X540 14mm lift cam, up to 1250cc)
-
-16mm Flat Top Plungers (X531 13mm lift cam, up to 1700cc)
-
-16mm Variable Timing Plungers (X531 13mm lift cam, up to 1700cc)
-
-3,000 / 3,500 / 4,500 & open RPM governor options
Simms
-
-12mm Plungers (TW Series, up to 550cc)
PFR
-
-Zexel 5.5mm Plunger - (80cc)
-
-Zexel 6mm Plunger - (140cc)
-
-Yanmar 6mm Plunger - (140cc)
-
-Denso 6mm Plunger - (100cc)
